A graphical color touch screen interfacing to the PLC provides the operator interface for test cell system controls and safety interlocks

bullet Engine starting
bullet Fuel system
bullet Dynamometer
bullet Anti ice
bullet Fault indication


bullet Ignition
bullet Bleed air
bullet Emergency stop
bullet Force to idle
bullet Safety interlocks
engine and facility control interface for engine test cell example 1 engine and facility control interface for engine test cell example 2 engine and facility control interface for engine test cell example 3 engine and facility control interface for engine test cell example 4
